Triple chevron pattern — free hatch (.pat), texture & 3D tiles

Triple chevron is a wood layout built from 6 tiles per repeat (sizes 643.3 × 75 mm), repeating on the lattice a = (1039.2, 0) mm, b = (0, 259.8) mm, a cell of 270000 mm². The seamless texture repeat is 1039.2 × 259.8 mm. Download it as a CAD hatch, a seamless texture or SVG and DXF lines, count the tiles for your room, or build it as real 3D tiles in SketchUp. All free.

Triple chevron tile pattern: tiles drawn with their joints

Triple chevron in numbers

CategoryWood floors and parquetry
Tiles in one repeat6
Lattice vector a(1039.2, 0) mm
Lattice vector b(0, 259.8) mm
Repeat cell area270000 mm²
Tile sizes643.3 × 75 mm
Seamless texture repeat1039.2 × 259.8 mm
Default plank length600 (range 50–3000)
Default plank width75 (range 10–500)
Default end cut angle (degrees)60 (range 10–90)

Free downloads for Triple chevron

The PAT files are approximate: this pattern has edges that a PAT line family cannot draw exactly, so they are drawn as stepped lines. SVG and DXF are exact.

Hatch units are millimetres at the default tile size. For other sizes use the hatch page or the editor, which exports every format at the size you set.

Triple chevron tile calculator

Enter the room, grout and tile size. The count comes from the same engine that lays the 3D tiles, so the cut tiles are real cuts against your room edges (a 4 × 3 m room is shown first). More patterns: tile calculator.

Full tiles
217
Cut tiles
94
Whole tiles used
311
Area (net)
12 m²
Tile area bought
14 m²
Waste from cuts
16.6 %
Tiles to order
343
Tiles by size
SizeFull tilesCut tiles
643.3 × 75 mm21794

Open it in the editor or in SketchUp

Open Triple chevron in the editor

Use it in SketchUp (10 free uses a day) motif.rbz

Questions about Triple chevron

How many Triple chevron tiles do I need for a 4 × 3 m room?

With the default tile size and a 3 mm joint, a 4 × 3 m floor needs 217 full tiles and 94 cut tiles (311 whole tiles counting each cut tile as one). The net area is 12 m² and the tiles bought cover 14 m², so cutting alone wastes 16.6 %. Enter your own room and tile size in the calculator on this page.

Is the Triple chevron hatch exact?

Not entirely. A PAT file can only hold straight dashed line families, and Triple chevron has edges that no such family reproduces exactly. The file draws 12 edges as a staircase of horizontal and vertical steps of 13 mm, within a fraction of a step of the true edge. The SVG and DXF downloads are exact.

How do I use the .pat file in AutoCAD?

Copy the .pat file into a folder that is in AutoCAD's Support File Search Path (Options > Files), keep the file name (the pattern name inside the file matches it), then pick the pattern in the HATCH command. If Windows blocks the download, right-click the file, open Properties and tick Unblock.

How do I use the .pat file in Revit?

In Revit open Manage > Additional Settings > Fill Patterns, click New, choose Custom and browse to the .pat file. Use the model variant when the pattern must keep its real size on the building.

What is the repeat size of Triple chevron?

One repeat of the lattice covers 270000 mm² with 6 tiles. The smallest rectangle that repeats seamlessly in both directions, which is what a texture image needs, is 1039.2 × 259.8 mm at the default sizes.
