Grass paver, square with round hole pattern — free hatch (.pat), texture & 3D tiles

Grass paver, square with round hole is a stone layout built from 1 tile per repeat (sizes 400 × 400 mm), repeating on the lattice a = (400, 0) mm, b = (0, 400) mm, a cell of 160000 mm². The seamless texture repeat is 400 × 400 mm. Download it as a CAD hatch, a seamless texture or SVG and DXF lines, count the tiles for your room, or build it as real 3D tiles in SketchUp. All free.

Grass paver, square with round hole tile pattern: tiles drawn with their joints

Grass paver, square with round hole in numbers

CategoryStone, paving and cobble
Tiles in one repeat1
Lattice vector a(400, 0) mm
Lattice vector b(0, 400) mm
Repeat cell area160000 mm²
Tile sizes400 × 400 mm
Seamless texture repeat400 × 400 mm
Default side400 (range 150–600)
Default corner cut (fraction of the side)0.1 (range 0–0.15)
Default hole diameter (fraction of the side)0.65 (range 0.3–0.85)

Free downloads for Grass paver, square with round hole

The PAT files are approximate: this pattern has edges that a PAT line family cannot draw exactly, so they are drawn as stepped lines. SVG and DXF are exact.

Hatch units are millimetres at the default tile size. For other sizes use the hatch page or the editor, which exports every format at the size you set.

Grass paver, square with round hole tile calculator

Enter the room, grout and tile size. The count comes from the same engine that lays the 3D tiles, so the cut tiles are real cuts against your room edges (a 4 × 3 m room is shown first). More patterns: tile calculator.

Full tiles
70
Cut tiles
10
Whole tiles used
80
Area (net)
7.78 m²
Tile area bought
8.3 m²
Waste from cuts
6.7 %
Tiles to order
88
Tiles by size
SizeFull tilesCut tiles
400 × 400 mm7010

Open it in the editor or in SketchUp

Open Grass paver, square with round hole in the editor

Use it in SketchUp (10 free uses a day) motif.rbz

Questions about Grass paver, square with round hole

How many Grass paver, square with round hole tiles do I need for a 4 × 3 m room?

With the default tile size and a 3 mm joint, a 4 × 3 m floor needs 70 full tiles and 10 cut tiles (80 whole tiles counting each cut tile as one). The net area is 7.78 m² and the tiles bought cover 8.3 m², so cutting alone wastes 6.7 %. Enter your own room and tile size in the calculator on this page.

Is the Grass paver, square with round hole hatch exact?

Not entirely. A PAT file can only hold straight dashed line families, and Grass paver, square with round hole has edges that no such family reproduces exactly. The file draws 112 edges as a staircase of horizontal and vertical steps of 20 mm, within a fraction of a step of the true edge. The SVG and DXF downloads are exact.

How do I use the .pat file in AutoCAD?

Copy the .pat file into a folder that is in AutoCAD's Support File Search Path (Options > Files), keep the file name (the pattern name inside the file matches it), then pick the pattern in the HATCH command. If Windows blocks the download, right-click the file, open Properties and tick Unblock.

How do I use the .pat file in Revit?

In Revit open Manage > Additional Settings > Fill Patterns, click New, choose Custom and browse to the .pat file. Use the model variant when the pattern must keep its real size on the building.

What is the repeat size of Grass paver, square with round hole?

One repeat of the lattice covers 160000 mm² with 1 tile. The smallest rectangle that repeats seamlessly in both directions, which is what a texture image needs, is 400 × 400 mm at the default sizes.
