Grass paver, 2 holes (figure 8) pattern — free hatch (.pat), texture & 3D tiles

Grass paver, 2 holes (figure 8) is a stone layout built from 1 tile per repeat (sizes 400 × 200 mm), repeating on the lattice a = (200, 0) mm, b = (0, 400) mm, a cell of 80000 mm². The seamless texture repeat is 200 × 400 mm. Download it as a CAD hatch, a seamless texture or SVG and DXF lines, count the tiles for your room, or build it as real 3D tiles in SketchUp. All free.

Grass paver, 2 holes (figure 8) tile pattern: tiles drawn with their joints

Grass paver, 2 holes (figure 8) in numbers

CategoryStone, paving and cobble
Tiles in one repeat1
Lattice vector a(200, 0) mm
Lattice vector b(0, 400) mm
Repeat cell area80000 mm²
Tile sizes400 × 200 mm
Seamless texture repeat200 × 400 mm
Default lobe width200 (range 100–400)
Default corner cut20 (range 5–20)
Default hole size0.8 (range 0.3–1)

Free downloads for Grass paver, 2 holes (figure 8)

Hatch units are millimetres at the default tile size. For other sizes use the hatch page or the editor, which exports every format at the size you set.

Grass paver, 2 holes (figure 8) tile calculator

Enter the room, grout and tile size. The count comes from the same engine that lays the 3D tiles, so the cut tiles are real cuts against your room edges (a 4 × 3 m room is shown first). More patterns: tile calculator.

Full tiles
140
Cut tiles
20
Whole tiles used
160
Area (net)
9.76 m²
Tile area bought
10.41 m²
Waste from cuts
6.7 %
Tiles to order
176
Tiles by size
SizeFull tilesCut tiles
400 × 200 mm14020

Open it in the editor or in SketchUp

Open Grass paver, 2 holes (figure 8) in the editor

Use it in SketchUp (10 free uses a day) motif.rbz

Questions about Grass paver, 2 holes (figure 8)

How many Grass paver, 2 holes (figure 8) tiles do I need for a 4 × 3 m room?

With the default tile size and a 3 mm joint, a 4 × 3 m floor needs 140 full tiles and 20 cut tiles (160 whole tiles counting each cut tile as one). The net area is 9.76 m² and the tiles bought cover 10.41 m², so cutting alone wastes 6.7 %. Enter your own room and tile size in the calculator on this page.

Is the Grass paver, 2 holes (figure 8) hatch exact?

Yes. The .pat file draws the tile edges exactly: every edge direction of this pattern is parallel to a lattice vector, so a PAT line family reproduces it without approximation. Units are millimetres and the pattern name inside the file is grass-paver-2.

How do I use the .pat file in AutoCAD?

Copy the .pat file into a folder that is in AutoCAD's Support File Search Path (Options > Files), keep the file name (the pattern name inside the file matches it), then pick the pattern in the HATCH command. If Windows blocks the download, right-click the file, open Properties and tick Unblock.

How do I use the .pat file in Revit?

In Revit open Manage > Additional Settings > Fill Patterns, click New, choose Custom and browse to the .pat file. Use the model variant when the pattern must keep its real size on the building.

What is the repeat size of Grass paver, 2 holes (figure 8)?

One repeat of the lattice covers 80000 mm² with 1 tile. The smallest rectangle that repeats seamlessly in both directions, which is what a texture image needs, is 200 × 400 mm at the default sizes.
