Tactile blister pattern — free hatch (.pat), texture & 3D tiles

Tactile blister is a stone layout built from 1 tile per repeat (sizes 45 × 45 mm), repeating on the lattice a = (66.8, 0) mm, b = (0, 66.8) mm, a cell of 4462 mm². The seamless texture repeat is 66.8 × 66.8 mm. Download it as a CAD hatch, a seamless texture or SVG and DXF lines, count the tiles for your room, or build it as real 3D tiles in SketchUp. All free.

Tactile blister tile pattern: tiles drawn with their joints

Tactile blister in numbers

CategoryStone, paving and cobble
Tiles in one repeat1
Lattice vector a(66.8, 0) mm
Lattice vector b(0, 66.8) mm
Repeat cell area4462 mm²
Tile sizes45 × 45 mm
Seamless texture repeat66.8 × 66.8 mm
Default pitch66.8 (range 50–80)
Default base diameter45 (range 30–49)

Free downloads for Tactile blister

The PAT files are approximate: this pattern has edges that a PAT line family cannot draw exactly, so they are drawn as stepped lines. SVG and DXF are exact.

Hatch units are millimetres at the default tile size. For other sizes use the hatch page or the editor, which exports every format at the size you set.

Tactile blister tile calculator

Enter the room, grout and tile size. The count comes from the same engine that lays the 3D tiles, so the cut tiles are real cuts against your room edges (a 4 × 3 m room is shown first). More patterns: tile calculator.

Full tiles
2700
Cut tiles
0
Whole tiles used
2700
Area (net)
4.28 m²
Tile area bought
4.28 m²
Waste from cuts
0 %
Tiles to order
2971
Tiles by size
SizeFull tilesCut tiles
45 × 45 mm27000

Open it in the editor or in SketchUp

Open Tactile blister in the editor

Use it in SketchUp (10 free uses a day) motif.rbz

Questions about Tactile blister

How many Tactile blister tiles do I need for a 4 × 3 m room?

With the default tile size and a 3 mm joint, a 4 × 3 m floor needs 2700 full tiles and 0 cut tiles (2700 whole tiles counting each cut tile as one). The net area is 4.28 m² and the tiles bought cover 4.28 m², so cutting alone wastes 0 %. Enter your own room and tile size in the calculator on this page.

Is the Tactile blister hatch exact?

Not entirely. A PAT file can only hold straight dashed line families, and Tactile blister has edges that no such family reproduces exactly. The file draws 48 edges as a staircase of horizontal and vertical steps of 3.3 mm, within a fraction of a step of the true edge. The SVG and DXF downloads are exact.

How do I use the .pat file in AutoCAD?

Copy the .pat file into a folder that is in AutoCAD's Support File Search Path (Options > Files), keep the file name (the pattern name inside the file matches it), then pick the pattern in the HATCH command. If Windows blocks the download, right-click the file, open Properties and tick Unblock.

How do I use the .pat file in Revit?

In Revit open Manage > Additional Settings > Fill Patterns, click New, choose Custom and browse to the .pat file. Use the model variant when the pattern must keep its real size on the building.

What is the repeat size of Tactile blister?

One repeat of the lattice covers 4462 mm² with 1 tile. The smallest rectangle that repeats seamlessly in both directions, which is what a texture image needs, is 66.8 × 66.8 mm at the default sizes.
